Tube Type Non-contact liquid level Sensor/Non-contact liquid level Switch/Non-contact liquid level Detector Sensor
Tube Type Non-contact liquid level Sensor/Non-contact liquid level Switch/Non-contact liquid level Detector Sensor
(Support bulk orders and Custom service orders )
Output choose :High and low level output,NPN output,PNP output
The input voltage (Vin)DC 5~24 V
Power flow 5mA
The input voltage (Vin) DC 5 ~ 24 V
The Power flow 5 ma
Output voltage Vin (high level)
Output voltage (low level) 0 v
Output current is 1 ~ 100 ma
Response time for 500 ms
Working environment temperature is 0 ~ 85 ℃
Induction sensitivity pipe diameter D (mm)
Induction biggest wall thickness (mm) L
D 100 or more
20 + 2
100 > D 80 or higher
15 + / - 2
> D 60 or 80
12 + / - 1.5
> 60 D 40 or higher
7-1.0
> 40 D 30 or more
5 + / - 1.0
> D 20 or 30
3 + / - 1.0
20 p > D 10
1.5 + / - 0.5
Apply pipe diameter range
10 mm or higher
Liquid level error
+ / - 1.5 mm
humidity
5% ~ 100%
The material
ABS.
Waterproof properties
IP65
